Gantry Cutting Machine

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1423837

• Place of Origin:

  China
• The machine is built in total cast iron with giant blade for extra cutting depth, with two columns that support and guide the vertical cutting units movement along the cast iron bridge, making vertical movement on the two precision screws with two worm screws.

  This machine is available for cutting and edging large scale Marble Granite Block.
  LMQJ-1600-2
  Max.cutting length mm 3000
  Max.cutting width mm 2000
  Max.cutting height mm 2000
  Max.blade diameter mm 1600
  Main motor power KW 37 or 55
  Water consumption m3/h 6
  Overall dimensions(L×W×H) mm 6000×4700×6000
  Approximate weight kg 7000

  The machine is CE certified for Gantry Cutting Machine with the features of high production capacity and good precision. The imported converter can well regulate the speed, and the trolley surface can rotate 360 degree.

  Adopting mechanics design, the machine has reasonable structure, good firmness and stable performance. Its processing sheet has large specifications and good quality. The machine is the ideal equipment for the processing of granite and marble and other kinds of stone materials.
